Electronic cigarette testing equipment

In addition to the detection of nicotine in e liquid, the quality of nebulizers and batteries in vapes is one of the issues we should pay attention to. The quality of the atomizer is mainly measured by resistance value, airflow, smoke volume, liquid leaking and working temperature. Battery quality testing is more cumbersome, including short-circuit protection, charging protection, over-current, charging time, smoking timeout protection and other testing items.

The electronic cigarette testing machine is used to test the performance of electronic cigarette smoker, electronic cigarette battery, tobacco rod, microphone, battery, cartridge or finished electronic cigarette life, and electronic cigarette suction value in one-way and two-way life. Instrument.

One, Electronic smoke leaking gas leak detection instrument

The electronic smoke leaking gas leak detection instrument is one of the series of electronic cigarette testing machines, and is mainly used for testing electronic cigarette smokers, electronic cigarette batteries (which can be measured by air suction or button-on) or the life of the finished electronic cigarette.

Second, the electronic cigarette life testing machine

Test the airflow through which the electronic cigarette passes, the life of the button, and the like.

Third, electronic cigarette resistance tester

The electronic cigarette resistance test is mainly used to measure the absorption resistance of electronic cigarettes, and is suitable for electronic cigarette production quality control and electronic cigarette inspection. When simulating a person's smoking action on an electronic cigarette and inhaling a fixed flow rate of 17.5 ml/s air, this time a certain vacuum pressure is generated at the suction end of the electronic cigarette. This pressure is the resistance of the suction, referred to as the suction resistance, and the measurement. With this pressure, the resistance can be measured.

Fourth, electronic cigarette air tightness testing machine

The electronic cigarette airtightness testing machine is mainly used for detecting the airtight device of the electronic cigarette assembly.

Five, electronic cigarette special controllable air blower

The electronic cigarette-specific controllable air blower is used for testing the electronic cigarette battery rod airflow sensing device. That is, after the welding of the hoe and the related electronic components, the air blowing test is performed by the machine, and if the welding is correct, the corresponding indicator light is illuminated. Each time the switch is pressed, the air nozzle is automatically turned off after a certain time delay.

Sixth, the electronic cigarette machine

The electronic cigarette ticker is one of the series of electronic cigarette testing machines, mainly used to test the battery life of electronic cigarettes or electronic cigarettes. The principle is to adjust a certain amount of inhalation or inspiratory pressure, and the nozzle sucks and stops the sample, so that the cycle is repeated until the vape or the vape battery is exhausted or dropped to a certain voltage, thereby judging the electron. The service life of smoke or electronic cigarette batteries is improved.

Seven, electronic cigarette resistance tester

The electronic cigarette resistance test is mainly used to measure the absorption resistance of electronic cigarettes, and is suitable for electronic cigarette production quality control and electronic cigarette inspection. When the simulated smoking action of the electronic cigarette absorbs the fixed flow air, a certain vacuum pressure is generated at the suction end of the electronic cigarette. This pressure is the resistance of the suction, referred to as the suction resistance, and the pressure can be measured. Resistance to resistance.

Eight, electronic cigarette cover shaft test machine

The electronic cigarette case cover shaft testing machine mainly detects the number or time of repeated opening/closing to complete breaking, and after a certain number of times or a certain time, whether the rotating shaft is damaged or not. The electronic cigarette case cover flip fatigue tester can simulate the electronic cigarette. The lid of the cigarette case is repeatedly opened and closed at a certain speed and angle.

Nine, electronic cigarette high altitude low air pressure testing machine

This kind of test is mainly in the battery test. The ultimate goal of the test is to see that the battery does not explode or ignite, does not smoke, does not leak, and the battery protection valve cannot be destroyed.
